Metallic and non-metallic options are NEMA 3R rated outdoor enclosures;
Easy-to-remove high-strength protective shield;
Easy-to-remove front cover;
Copper-rated line and load lugs;
Ample wiring space for mounting with a stud gun;
Padlock-able door provision for safety and reduction of tampering;
Factory-installed tamper resistant/weather-resistant ground fault receptacles.
Cat.No. | Description | Main Ampere Rating | HP Rating | HP Rating | Wire Size(AWG) & Torque Cu/AL | |
LINE/LOAD | GROUND | |||||
PCDS-60A | Enclosed Fused ACD | 60AMP 240V 1 PHASE 2-Pole 3-WIRE | STD.1.5 MAX.3 | STD.3 MAX.10 | #14-10 35LB-IN | #14-10 25LB-IN |
